Designing a Versioned Engineering Workflow for a Manufacturing ERP

The first Tag and Part screens looked like ordinary administration pages. There were records to list, forms to open, relationships to select, and quantities to validate. The difficult part appeared later: what should happen when Engineering needs to change a definition that has already progressed through approval?

Editing the same rows forever would keep the UI simple, but it would erase the meaning of the earlier engineering state. A changed Part would look as if it had always been that way. A deleted Part would disappear from the definition that previously contained it. The frontend had to represent a process closer to controlled revision than ordinary CRUD.

The handoff was a lifecycle boundary

The existing business process starts with a Project in Sales. A Project can contain multiple Tags, and each Tag groups the engineering definition for a product within that Project. Final Project approval hands the relevant work into Engineering, but it does not make Engineering another set of editable fields on the Sales form.

The Engineering work follows its own workflow. That separation mattered in the frontend. Project context still had to remain visible, but Engineering needed its own routes, forms, permissions, and progression. The Project approval and the Engineering Edition state answer different questions: one establishes that the handoff may begin; the other controls how the engineering definition can evolve.

Edition 0 was not a placeholder

The initial Edition is numbered zero, but its role is not technical scaffolding. It is the first engineering definition created after the Sales-to-Engineering handoff. Engineering progressively completes Tag information, associated product information, groups, and the Part List inside that context.

Early frontend work exposed Edition numbers as if they were ordinary form input even after numbering had become system-assigned. That inconsistency was a symptom of the model still settling. Once an Edition number expresses sequence rather than user-authored data, letting the form edit it creates the wrong expectation. Later Editions should follow the previous completed definition, not an arbitrary number entered by a user.

Edition creation also needed workflow gating. A later revision belongs after the prior Edition has reached the appropriate completed state. The implementation evolved around that rule rather than assuming a user could create unlimited parallel Editions. I modeled the frontend around the existing process; I did not design the company's approval workflow itself.

A revision is more than a copied list

Once later Editions existed, the Part List needed to describe change. A Part in a new Edition might be added, removed, or modified relative to the earlier definition. For a modification, the new row can keep a lineage reference to its predecessor. That gives the UI and later reporting enough context to distinguish “this is a different item” from “this is the revised form of an earlier item.”

Revision-aware update and deletion therefore behave differently depending on where a Part originated. If it already belongs to the current draft Edition, it can be edited or removed within that draft. If it was inherited from an earlier Edition, changing it creates a current-Edition representation and marks the relationship to the previous Part. Removing an inherited Part records removal rather than erasing the historical row.

The first revision implementation was not complete. Some lookup wiring was provisional, and the early selection of a previous Part did not yet express the final lineage behavior. Later work moved that responsibility away from a user-selected placeholder and into the revision operation itself. Across repeated revisions, the lineage can continue to point through the original predecessor instead of becoming an accidental chain of unrelated copies.

Routes carried the context that modals could not

Tags, Editions, groups, and Parts form a hierarchy. The first temptation is to manage each child in a modal opened from its parent. That works for a small lookup. It becomes awkward when the child has its own table, form, workflow state, validation, and another level of children.

I implemented these resources as routed administration experiences with parent-aware queries and breadcrumbs. A reader of the page can see which Project, Tag, or group they are working inside, and a direct route still carries the identity needed to reload that context. This followed the broader frontend direction of moving complex child-resource management out of nested modals.

Nested creation also needed safe defaults. When a group is created from a Tag context, the parent selection should already be set and should not be casually changed to another Tag. Several route and form contracts were inconsistent during the early rollout; making the route parameter, parent query, breadcrumb, and form default explicit reduced that ambiguity.

Current state and history cannot be queried the same way

Versioning creates a subtle data problem: historical rows remain useful, but they are not automatically part of the active definition. An early completeness check traversed Parts across Editions. That could make an incomplete current Edition appear complete because older Parts were still present in history, or make validation reason about rows that no longer represented the active engineering state.

The confirmed business boundary is narrower. Completeness must be evaluated against the relevant current or final Edition. Earlier Editions explain how the definition reached this point; they should not be blindly aggregated into the structure being approved now. Later implementation in another stage filtered by the current Edition correctly, while an earlier material check still crossed that boundary. I treat that difference as an implementation defect to resolve, not as two valid interpretations of the workflow.

The same rule matters for reports and downstream work. A report must be generated for an intentional Edition context. “All Parts ever associated with this Tag” is not equivalent to “the engineering definition that is current for this stage.” The public article does not need the internal templates or payloads to make that distinction clear.

Expected quantity should validate, not rebuild

A related mistake appeared around expected collection sizes. The Project records how many Tags are expected, and a Tag records how many associated products are expected. It is tempting to treat a quantity change as an instruction to clear and recreate the collection. That is dangerous once those children contain engineering data, files, workflow history, or references from later stages.

The confirmed model is non-destructive. Expected quantity is a completeness constraint, not ownership of the child collection. The system compares the expected count with actual records and blocks completion when they do not match. A user then resolves the mismatch explicitly by adding or removing the appropriate records, subject to the lifecycle's editing rules.

Some transitional service branches still attempted clear-and-recreate behavior. They conflict with this product rule and should be treated as remnants to remove, not as the intended architecture. This was one of the places where reviewing the business meaning changed how I judged code that might otherwise look like convenient synchronization.

Item identity also depended on position

Part matching introduced another domain detail. A material or catalog item is not always a complete engineering identity. The same item can appear in different positions inside an assembly. A hierarchical position such as3.2.1 can distinguish those occurrences: item 1 inside subgroup 2 of main group 3.

3
└── 3.2
    └── 3.2.1

Early copy and revision paths did not apply that identity consistently. One pre-copy check compared both the item and its nested position, while the copy operation de-duplicated by item alone and did not preserve the position. Some inherited revision clones also omitted it. The mismatch matters: two equal items in different assembly positions are not necessarily duplicates.

I would now treat the equivalence rule as one shared domain operation used by copy, revision, duplicate checks, and validation. Leaving each path to construct its own idea of identity is how small differences become history corruption later.

The UI had to make lifecycle boundaries visible

Forms and row actions cannot be enabled only because an endpoint exists. Edits belong to the appropriate draft state. Group creation, Part changes, and revision operations need to reflect which Edition is current and where its workflow stands. Several gates changed while the process was being clarified; one early check even required an Edition to be complete before allowing the groups needed to complete it. That was later corrected to the draft stage.

These restrictions are easier to understand when the route preserves parent context, the table shows revision state, and actions disappear or reject work consistently. A generic disabled form is not enough. The frontend has to explain whether the reader is viewing history, editing the current draft, or starting a later revision.

What I would establish earlier now

I would start by writing down three domain boundaries before building the forms: which Edition represents the active definition, what makes two Parts equivalent across revisions, and which operations are legal in each workflow state. Those rules should drive queries, validation, copy logic, action policies, and reports from the same source.

I would still keep the routed hierarchy. Complex engineering resources need room for their own state and history, and the URL is a useful boundary for parent context. I would also keep lineage explicit rather than inferring change by comparing two arbitrary snapshots in the frontend.

The unresolved edge is not whether Editions are useful. It is making every path honor the same Edition boundary. A validation query that aggregates history, a copy operation that drops positional identity, or a report that selects an ambiguous Edition can each undermine an otherwise correct UI. That is the part I would test as a domain contract, not leave distributed across individual screens.
